Asus ROG Maximus Z790 Dark Hero WiFi D5 Motherboard
- Intel® LGA 1700 socket: Ready for 13th, 14th & 12th Gen Intel Core, Pentium Gold and Celeron Processors
- Robust Power Solution:Â 20 + 1 +2 teamed power solution rated for 90A per stage with dual ProCool II power connectors, high-quality alloy chokes, and durable capacitors to support multi-core processors
- Optimized VRM Thermals:Â Massive heatsinks integrated with the I/O cover, joined by an L-shaped heatpipe, and connected to the power stages with high-conductivity thermal pads
- Next-Gen M.2 Support: PCIe 5.0 M.2 slot on the bundled ROG Hyper M.2 card, and four PCIe 4.0 M.2 slots all with substantial cooling solutions
- Abundant Connectivity:Â Dual Thunderbolt 4 USB Type-C ports, USB 3.2 Gen 2×2 Type-C front-panel connector with Quick Charge 4+ up to 60W, six additional USB 3.2 Gen 2 ports, two PCIe 5.0 x16 SafeSlots, HDMIÂ 2.1
- High-Performance Networking:Â On-board Intel WI-FI 6E (802.11ax) and Intel 2.5 Gb Ethernet with ASUS LANGuard
- Intelligent Control:Â ASUS-exclusive AI Overclocking, AI Cooling II, AI Networking and Two-Way AI Noise Cancelation to simplify setup and improve performance
- Immersive Audio:Â ROG SupremeFX ALC4082 codec with ESSÂ ES9218 Quad DAC for up to 32-Bit/384 kHz playback
- Unmatched Personalization: I/O cover with Polymo Lighting, three addressable Gen 2 headers and one RGB header, all configurable with ASUS-exclusive Aura Sync RGB lighting
- DIY Friendly Design: PCIe Slot Q-Release, M.2 Q-Latch, pre-mounted I/O shield, Q-Code, Q-LED, FlexKey button, Start button, BIOS FlashBack™ button, and Clear CMOS button
- 3 Years Manufacturer Warranty. Know More >
FREE shipping on all orders, anywhere in India
Experienced PC experts to guide you before and after purchase
Quick Dispatch– Your order ships within 1–3 days
ROG Maximus Z790Dark Hero
The ROG Maximus Z790 Dark Hero boasts robust cooling, WiFi 7 and ample PCIe 5.0 slot for unmatched performance, and it offers full compatibility with 14th Gen Intel Core processors. Meanwhile, its stealthy design is accentuated by new Polymo lighting, which illuminates the I/O shroud with a microstructural array of dual-layer RGB and adds a personalized touch of style to your gaming setup.
ROG OVERCLOCKING TECHNOLOGIES
Psyche up and engage the Dark Hero overclocker in you, with onboard intelligence to scan, predict, and adapt CPU performance parameters, and tools to command and track system vitals.
AI OVERCLOCKING
Tuning is now faster and smarter than ever before. ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push the system to its limits. Predicted values can be engaged automatically or used as a launching ground for further experimentation.
DIFFERENTIAL SENSING
Conventional motherboards use single-ended sensing tapped from a location that isn’t ideal, leading to a large disparity between the actual voltage fed to the CPU and the value reported to software. The ROG Maximus Z790 Dark Hero features a differential-sensing circuit and delicate IC that simplify overclocking and tuning by allowing you to track voltages more accurately
WIFI 7
Next-gen WiFi 7* chipset introduces all-new ultrawide 320 MHz channel bandwidth in the 6 GHz band and 4096 QAM, delivering up to 2.4X ultra-fast WiFi speeds**. The revolutionary Multi-Link Operation (MLO) provides a more stable WiFi connection and lower latency, unlocking the realms of the unknown in gaming, streaming, and industrial IoT
| Model | ROG MAXIMUS Z790 DARK HERO |
| CPU | Intel Socket LGA1700 for 12th,13th&14th Gen Core, Pentium Gold and Celeron Processors* |
| Chipset | Intel Z790 Chipset |
| Memory | 4 x DIMM slots, Max. 192 GB, DDR5 7600+(OC) Upto |
| Storage | Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports* |
| USB | Rear USB Port ( Total 12Â ) |
| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082* |
| Special Features | ASUS ROG PROTECTION, Digi+,ASUS Thermal Solution,Aura Sync |
| Warranty | 3 Years |
| Brand |
ASUS |
|---|---|
| Platform |
INTEL |
| Socket |
LGA1700 |
| Chipset |
Z790 |
| Form Factor |
ATX |
| Memory Type |
DDR5 |
| Memory Slots |
4 |
| Light Sync |
RGB ,ARGB |
